The Lumagen Radiance Pro is a multifaceted device that offers an array of advanced calibration and control features. With the ability to calibrate grayscale and color points, support the Rec. 2020 color space and BT.2084 HDR EOTF, and function as an HDR test pattern generator, the Radiance Pro caters to the needs of professionals seeking precise and innovative display calibration. Control of the device can be achieved through the use of a USB cable or a DB-9 female to DB-9 female null-modem RS-232 cable, with the option to enable the Radiance RS-232 Echo. Additionally, a device driver pack, which includes the Lumagen Radiance Pro, is available for download. Calman, a renowned calibration software, offers recommended workflows such as the Color Cube (3D LUT) for grayscale and color calibration, as well as the HT Advanced or SI Advanced for grayscale and CMS color calibration. The integration of Calman allows for the calibration and loading of LUT data into the Radiance Pro, with the option to enable color gamut options in the device menu. In summary, the Lumagen Radiance Pro presents professional users with a comprehensive solution for advanced calibration and control needs.

Key Takeaways

  • The Lumagen Radiance Pro features the ability to calibrate grayscale and color points, supports Rec. 2020 color space and BT.2084 HDR EOTF, functions as an HDR test pattern generator, and requires firmware version 092316 or newer.
  • Calman recommends using the Color Cube (3D LUT) or HT Advanced/SI Advanced workflows for calibration with the Lumagen Radiance Pro.
  • The Radiance Pro can be controlled via a USB cable or a serial cable, and the Radiance RS-232 Echo must be On for control.
  • Calman can calibrate and load LUT data into the Radiance Pro, with options to enable color gamut options and select the number of 3D LUT points.

Features

The Lumagen Radiance Pro is a device that offers various features such as grayscale and color point calibration, support for Rec. 2020 color space and BT.2084 HDR EOTF, and the ability to function as an HDR test pattern generator, among others. It is not suitable for full range/PC levels. With firmware version 092316 or newer, the Radiance Pro can be used as an HDR test pattern generator. It can be controlled through a USB cable or a serial cable using a DB-9 female to DB-9 female null-modem RS-232 cable. The Radiance RS-232 Echo must be turned on for control. The Calman software provides recommended workflows for calibration, such as the Color Cube (3D LUT) and HT Advanced or SI Advanced for grayscale and color management system (CMS) calibration. The Device Driver Pack includes the Lumagen Radiance Pro and can be downloaded from the Calman Downloads page. Calman can calibrate and load 1D and 3D LUT data into the Radiance Pro, with the number of 3D LUT points being selectable. The Calman Color Cube (3D LUT) workflow is used to create display calibration 3D cube LUTs, with options to choose the linear or source mode for the LUT.

Calman offers a selection of recommended workflows that guide users through the process of calibrating and controlling a device for optimal performance. These workflows help ensure accurate grayscale and color calibration on the Lumagen Radiance Pro. Users can choose from different workflows depending on their calibration needs. The Color Cube (3D LUT) workflow is used to create display calibration 3D cube LUTs. It involves connecting a color meter and source, selecting the Lumagen Radiance Pro as the LUT device, and choosing the linear or source mode for the 3D LUT. Another option is the HT Advanced or SI Advanced workflow, which is used for grayscale and CMS color calibration. These workflows provide users with the tools and guidance necessary to achieve precise calibration results on the Lumagen Radiance Pro.

Workflow Purpose
Color Cube (3D LUT) Creates display calibration 3D cube LUTs
HT Advanced Grayscale and CMS color calibration
SI Advanced Grayscale and CMS color calibration

Control Connection

One way to establish a control connection with the Lumagen Radiance Pro is through a USB cable or a serial cable. This connection allows for communication between the calibration software, like Calman, and the Radiance Pro device.

To further illustrate the process, here are three key points to consider:

  • USB cable: By connecting the Radiance Pro to the computer using a USB cable, the control commands and data can be transmitted directly from the computer to the device.
  • Serial cable: Alternatively, a serial cable, specifically a DB-9 female to DB-9 female null-modem RS-232 cable, can be used for the control connection. This cable facilitates the transfer of control signals and data between the computer and the Radiance Pro.
  • Radiance RS-232 Echo: It is essential to have the Radiance RS-232 Echo feature turned on for control. This ensures that the control commands sent from the calibration software are received and executed by the Radiance Pro accurately.

Establishing a control connection via USB or serial cable allows for seamless communication and control over the Lumagen Radiance Pro during the calibration process, enabling precise and advanced calibration adjustments.

Device Driver Pack

The Device Driver Pack is a compiled pack of drivers that includes support for various hardware devices, including the Lumagen Radiance Pro, and is easily accessible on the Calman Downloads page. This pack is designed to facilitate the integration and control of the Lumagen Radiance Pro with Calman software. By installing the Device Driver Pack, users can ensure seamless communication between the Radiance Pro and Calman, enabling advanced calibration and control capabilities. The Device Driver Pack serves as a bridge between the software and the hardware, allowing users to take advantage of the Radiance Pro’s features, such as grayscale and color point calibration, support for Rec. 2020 color space and BT.2084 HDR EOTF, and functioning as an HDR test pattern generator. It is an essential component for users seeking innovative solutions for display calibration and control.
